22
20
1
Shaft Bolt - Stainless Steel (IEC Motors Only)
IEC 90 B14, IEC 100-112 B14 - M8-1.25 x 25mm hex head cap screw J103662
IEC 100-112 B14 - M10-1.5 x 35mm fillister head cap screw 108582
IEC 132 B5 - M12-1.75 x 30mm hex head cap screw 106507
IEC 160 B5 - M16-2 x 35mm hex head cap screw 108270
21 2
Shaft Adapter Hex Nut - Stainless Steel
M8 J103930
22 4
Shaft Adapter Lock Washer - Stainless Steel
5/16” J102282
23 2
Shaft Adapter Hex Head Cap Screw - Stainless Steel
M8-1.25 x 25mm J103662
27 2
Shaft Adapter Set Screw - Stainless Steel
3/8-16 x 3/8 knurled cup point J101084
*For IEC 132 B5 motors, hardware to attach the motor (not shown) to the motor adapter (Item 9) is to be supplied by the customer due to variations in B5 frame motors.
**For IEC 160 B5 pumps, these bolts attach the motor adapter (Item 9) to supplied motor adapter flange (Item 10). Hardware to attach motor (not shown) to motor adapter
flange (item 10) is to be supplied by the customer due to variations in B5 frame motors.
