Finish Thompson UC - Manual (Page 19)

19
UC Spare Parts
Item Qty Description Part Number
1 1
Casing - ETFE-lined Cast Ductile Iron
UC1516 A103145
UC1518 A103146
UC326 A103147
2 1
Front Shaft Support Only (2A sold separately)
ETFE M102206
2A 1
Front Thrust Ring Only - Silicon Carbide
All models except UC1516 w/ SiC impeller thrust ring option J103659
UC1516 pumps w/ silicon carbide impeller thrust ring option only J104174
3 1
Impeller Assembly
ETFE See charts on pg. 23
3A 1
Impeller Thrust Ring
For UC1516 - Fluorosint ® J103900-1
For UC1518 - Fluorosint ® 106950
For UC326 - Fluorosint ® J103900-2
For UC1516 - Silicon Carbide J104172
For UC1518 - Silicon Carbide J104171
For UC326 - Silicon Carbide J104173
3B 1
Impeller Thrust Ring O-Ring - For Use With Silicon Carbide Thrust Ring Only (Not Shown)
UC1516 - PTFE Encapsulated FKM 108037
UC1516 - FKM J104186
UC1516 - EPDM J104187
UC1518 / UC326 - PTFE Encapsulated FKM 108038
UC1518 / UC326 - FKM J104189
UC1518 / UC326 - EPDM J104190
4 1
Impeller Drive Hub Assembly - ETFE
“A” magnet 108476-1
“B” magnet 108476-2
4A 2
Bushing
Silicon carbide J103653-1
Carbon J103653-2
Silicon carbide with Dri-Coat diamond-like coating J103653-3
4B 1
Bushing Spacer - PTFE
UC1516 M102207-2
UC1518 / UC326 M102207-1
4C 1
Rear Sealing Ring
PTFE 108482
5 1
Shaft
Silicon carbide J103643
Silicon carbide with Dri-Coat diamond-like coating J103643-1
6 1
Barrier Assembly - ETFE/FRP
UC1516 / UC326 108483-1
UC1518 108483-2
7 1
Clamp Ring
Painted steeel M102184
