1 42
TA B L E O F C O N T E N T S
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CHECKLISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY SIGNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PREPARATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . 17
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . 21
OWNER MAINTENANCE & LUBRICATION . . . . . . . . . . . . . 24
TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
PARTS LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
STATEMENT
OF POLICY
It is the policy of Worksaver,
Inc. to improve its products
where it is possible and practical
to do so. Worksaver, Inc.
reserves the right to make
changes or improvements in
design and construction at any
time, without incurring the oblig-
ation to make these changes on
previously manufactured units.
T O T H E O W N E R :
Read this manual before using your Rotary Mower. This manual is provided to give you the necessary operating
and maintenance instructions for keeping your rotary mower in top operating condition. Please read this manual
thoroughly. Understand what each control is for and how to use it. Observe all safety signs on the machine and
noted throughout the manual for safe operation of implement. Keep this manual handy for ready reference.
Like all mechanical products, it will require cleaning and upkeep. Lubricate the Mower as specified.
Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet stan-
dards required for safe and satisfactory operation. Record the model and serial number of your Mower here:
Model:________________________________________ Serial Number:_______________________________
RETAIL CUSTOMER’S RESPONSIBILITY
It is the Retail Customer and/or Operator’s responsibility to read the Operator’s Manual, to operate, lubri-
cate, maintain, and store the product in accordance with all instructions and safety procedures. Failure
of the operator to read the Operator’s Manual is a misuse of this equipment.
It is the Retail Customer and/or Operator’s responsibility to inspect the product and to have any part(s)
repaired or replaced when continued operation would cause damage or excessive wear to other parts or
cause a safety hazard.
It is the Retail Customer’s responsibility to deliver the product to the authorized Worksaver Dealer, from
whom he purchased it, for service or replacement of defective parts which are covered by warranty.
Repairs to be submitted for warranty consideration must be made within forty-five (45) days of failure.
It is the Retail Customer’s responsibility for any cost incurred by the Dealer for traveling to or hauling
of the product for the purpose of performing a warranty obligation or inspection.
SINO LEEINGLES, PIDA AYUDA A
AIGUIEN QUE SI LO LEA PARA QUE
LE TRADUZCA LAS MEDIDAS DE
SEGURIDAD. PTO SHAFT (SLIP CLUTCH PROTECTED)
PA RTS LIST
REF. WORKSAVER REF. NO.
NO. PART NO. (E & G) DESCRIPTION QTY.
650472 07.582.033.10 Complete Driveline Assembly (MDM70-60) 1
650475 07.582.024.10 Complete Driveline Assembly (MDM70-72) 1
1 650701 141.025.001 Push Pin Yoke 1
2 650702 180.015.130 Cross Journal Set 2
5 650703 151.015.011 Outer Yoke 1
11 650704 190.000.016 Roll Pin for Outer Tube 1
14 650738 Outer Tube (MDM70-60) 1
650759 152.150.212 Outer Tube (MDM70-72) 1
15 650739 Inner Tube (MDM70-60) 1
650760 153.150.112 Inner Tube (MDM70-72) 1
16 650707 190.000.394 Roll Pin for Inner Tube 1
21 650708 151.015.012 Inner Yoke 1
30 650740 146.252.011 Complete Disc Clutch 1
31 650710 180.015.009 Guard Retaining Collar for Outer Tube 1
32 650711 180.026.023 Cone for Outer Tube 1
33 650712 190.000.019 Bolt 6
34 650741 Outer Shield (MDM70-60) 1
650761 156.151.112.7520 Outer Shield (MDM70-72) 1
35 650742 Inner Shield (MDM70-60) 1
650762 157.151.212.7521 Inner Shield (MDM70-72) 1
36 650743 158.025.041 Cone for Inner Tube 1
37 650716 180.015.008 Guard Retaining Collar for Inner Tube 1
38 650717 180.016.025 Safety Chains 2
40 650744 Complete Guard with Instr. Manual (MDM70-60) 1
650763 142.250.007.7520 Complete Guard with Instr. Manual (MDM70-72) 1
51 650719 166.026.004 Push Pin Set 1 3 / 8 ” 1
71 650745 180.019.017 Spring 8
72 650746 151.015.038 Flanged Yoke 1
73 650747 180.019.019 Bush 1
74 650748 180.019.018 Lining Ring 2
75 650749 165.000.502 Bolt M12 x 1.25 x 65 & Nut 2
76 650750 151.018.018 Clutch Support 1
77 650751 180.019.014 Inner Plate 1
78 650752 180.019.116 Pressure Plate 1
79 650753 165.000.549 Bolt M10 x 85 & Nut 8
90 650720 121.025.506.10 U Joint for Outer Tube 1
91 650754 121.025.545.10 U Joint for Inner Tube 1
94 650755 Half Female Guard (MDM70-60) 1
650764 142.251.170.7520 Half Female Guard (MDM70-72) 1
95 650756 Half Male Guard (MDM70-60) 1
650765 142.251.247.7521 Half Male Guard (MDM70-72) 1
96 650757 Half Female Shaft with Guarding (MDM70-60) 1
650766 123.250.708.10 Half Female Shaft with Guarding (MDM70-72) 1
97 650758 Half Male Shaft with Guarding (MDM70-60) 1
650767 123.250.398.10 Half Male Shaft with Guarding (MDM70-72) 1
98 650726 190.000.098 “DANGER” Label for Outer Tube 1
99 650727 190.000.099 “DANGER” Label for Outer Guard Tube 1
100 650728 190.000.371 Instruction Manual 1
