D E L I V E RY C H E C K L I S T
Inspect the mower thoroughly after assembly to be cer-
tain it is set up properly. The following checklist is a
reminder of points to inspect. Check off each item as it is
found satisfactory or after proper adjustment is made.
h
Check operator's manual and familiarize the opera-
tor with all sections of it.
h
Check that all safety shielding is in place.
h
Check all bolts to be sure they are tight or adjusted
properly at hinged locations.
h
Check that all cotter pins are properly installed.
h
Check PTO driveline. Make sure it is the correct
length to operate mower with intended tractor.
h
Check that all lubrication points with grease fittings
have been lubricated.
h
Check that blades have been properly installed.
Check all blade beam bolts.
h
Check mower attitude, after mounting on tractor.
h
Check that gearbox is properly serviced and seals
are not leaking.
h
Check shear bolt for proper grade and installation.
h
Check front of input gearbox shaft and make sure
that snap ring is properly installed. (Shearbolt Model)
h
All safety signs (decals) in place and readable.
h
When the cutter is transported on a road or highway
at night or during the day, safety devices should be
used for adequate warning to operators of other
vehicles.
C H E C K L I S T S
I M P O RTA N T !
Gearbox was not filled at factory. It
must be serviced before operating.
Fill to proper level with SAE 90 oil.
Failure to service will result in
damage to gearbox.
P R E - O P E R AT I O N C H E C K L I S T
(OWNER/OPERATOR RESPONSIBILITY)
____ Review and follow safety rules and safety signs on
pages 4 through 16.
____ Check that mower is properly and securely
attached to tractor.
____ Make sure driveline spring-activated locking pin or
locking balls operate freely and are seated firmly in
tractor PTO spline groove.
____ Lubricate all grease fitting locations. Make sure
PTO shaft slip joint is lubricated.
____ Check to be sure gear lube runs out the small
check plug on side of gearbox.
____ Check that all hardware is properly installed.
____ Check to ensure blades are sharp and secure and
cutting edge is positioned to lead in a counter-
clockwise rotation.
____ Check that all shields and guards are properly
installed and in good condition.
____ Check cutting height, front to rear attitude and top
link adjustment.
____ Place tractor PTO and transmission in neutral
before starting engine.
____ Set tractor PTO gear select lever for 540 rpm
operation.
____ Inspect area to be cut and remove stones,
branches or other hard objects that might be
thrown, causing injury or damage.
____ Check that PTO driveline shields are securely
locked and clears the front of the mower frame.
____ Adjust the tractor top link so the front of the mower
is slightly above the rear. Then raise the tractor lift
very slowly, making sure that the front drive shaft
shield does not hit the front of the mower. If it does,
damage will be done to the drive shaft shield and,
if it hits hard enough, it will also damage the drive
shaft itself. (See page 20 – items 9 and 10.)
NOTE: This type of damage is not covered
under warranty, as it is totally under the control
and the responsibility of the operator.
P T O S H A F T ( S H E A R B O LT P R O T E C T E D )
PA RTS LIST
REF.
WORKSAVER
REF. NO.
NO.
PART NO.
(E & G)
DESCRIPTION
QTY.
650479
07.522.064.10
Complete Driveline Assembly (MDM70-60)
1
650470
07.522.066.10
Complete Driveline Assembly (MDM70-72)
1
1
650701
141.025.001
Push Pin Yoke 112
1
2
650702
180.015.130
Cross Journal Set
2
5
650703
151.015.011
Outer Yoke
1
11
650704
190.000.016
Roll Pin for Outer Tube
1
14
650705
152.150.345
Outer Tube (MDM70-60)
1
650729
152.150.337
Outer Tube (MDM70-72)
1
15
650706
153.150.348
Inner Tube (MDM70-60)
1
650730
153.150.349
Inner Tube (MDM70-72)
1
16
650707
190.000.394
Roll Pin for Inner Tube
1
21
650708
151.015.012
Inner Yoke
1
30
650709
151.015.037
Special Yoke
1
31
650710
180.015.009
Guard Retaining Collar for Outer Tube
1
32
650711
180.026.023
Cone for Outer Tube
1
33
650712
190.000.019
Bolt
6
34
650713
156.161.182.7520
Outer Guard (MDM70-60)
1
650731
156.161.345.7520
Outer Guard (MDM70-72)
1
35
650714
157.161.281.7521
Inner Guard (MDM70-60)
1
650732
157.161.444.7521
Inner Guard (MDM70-72)
1
36
650715
158.025.054
Long Cone for Inner Tube
1
37
650716
180.015.008
Guard Retaining Collar for Inner Tube
1
38
650717
180.016.025
Safety Chains
2
40
650718
142.250.028.7520
Complete Guard with Instr. Manual (MDM70-60)
1
650733
142.250.030.7520
Complete Guard with Instr. Manual (MDM70-72)
1
51
650719
166.026.004
Push Pin Set 1
3
/
8
”
1
90
650720
121.025.506.10
U Joint for Outer Tube
1
91
650721
121.025.586.10
U Joint for Inner Tube
1
94
650722
142.251.166.7520
Half Female Guard (MDM70-60)
1
650734
142.251.183.7520
Half Female Guard (MDM70-72)
1
95
650723
142.251.275.7520
Half Male Guard (MDM70-60)
1
650735
142.251.277.7520
Half Male Guard (MDM70-72)
1
96
650724
123.250.731.10
Half Female Shaft with Guarding (MDM70-60)
1
650736
123.250.734.10
Half Female Shaft with Guarding (MDM70-72)
1
97
650725
123.250.426.10
Half Male Shaft with Guarding (MDM70-60)
1
650737
123.250.428.10
Half Male Shaft with Guarding (MDM70-72)
1
98
650726
190.000.098
“DANGER” Label for Outer Tube
1
99
650727
190.000.099
“DANGER” Label for Outer Guard Tube
1
100
650728
190.000.371
Instruction Manual
1
