S A F E T Y I N S T R U C T I O N S (continued)
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment.
Designers and manufacturers build in as many safety features as possible. However, every year many
accidents occur which could have been avoided by a few seconds of thought and a more careful approach to
handling equipment. You, the operator, can avoid many accidents by observing the following precautions in
this section. To avoid personal injury, study the following precautions and insist those working with you, or for
you, follow them.
In order to provide a better view, certain photographs or illustrations in this manual may show an assembly
with a safety shield removed. However, equipment should never be operated in this condition. Keep all shields
in place. If shield removal becomes necessary for repairs, replace the shield prior to use.
To prevent injury or death, use a tractor equipped with a Roll-Over Protective System (ROPS). Do not paint
over, remove or deface any safety signs or warning signs on your equipment. Observe all safety signs and
practice the instruction on them.
Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question -
DON’T TRY IT.
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety and
could affect the life of the equipment.
In addition to the design and configuration of this implement, including Safety Signs and Safety Equipment,
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also
to Safety Messages and Operation instruction in each of the appropriate sections of the Tractor and Mower
Manuals. Pay close attention to the Safety Signs affixed to the Tractor and the Mower.
Replace any CAUTION, WARNING, DANGER or instruction safety sign that is not readable or is missing.
Location of such safety signs is indicated in this booklet.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this
equipment. Consult your doctor about operating this machine while taking prescription medications.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator should be a
responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not allow per-
sons to operate or assemble this unit until they have read this manual and have developed a thorough
understanding of the safety precautions and of how it works.
EQUIPMENT SAFETY GUIDELINES
C O M E R G E A R B O X 1 1 6 . 8 0 5
PA RTS LIST
REF. WORKSAVER COMER NO.
NO. PART NO. PART NO. DESCRIPTION REQ'D.
1 650411 0.116.0303.02 Casing 1
2 650478 0.116.1301.01 Cover 1
3 650419 8.0.1.00049 Bearing 6307 1
4 171014 0.259.7500.00 Shim 48.0 1
5 650483 0.116.2002.00 Shaft 1 3 / 8 ” 1
6 709052 8.6.5.00006 Plug 3 / 8 ” Gas 3
7 650431 0.116.6204.00 Pinion Z14 M5.7 1
8 650422 0.712.7500.00 Shim 70.3 1
9 650423 8.0.9.00469 Bearing 30210 2
10 650424 0.116.7102.01 Spacer 1
11 650484 0.132.7106.00 Nut M30 x 1.5 1
12 650486 0.116.3203.00 Shaft ASA DP 8/16 1
13 650481 8.1.1.00041 Bolt M8 x 22 8.8 8
14 650487 0.139.7000.00 Blank Washer 1
15 650434 8.2.2.00555 Castle Nut M30 x 2 PR80 1
16 650436 8.3.7.00140 Spring Washer 8.4 x 13 x 1.2 8
17 650437 8.7.2.00545 Double Lip Seal 50 x 68 x 10 1
18 650438 0.116.1701.04 Cover 1
19 650488 8.1.1.01257 Bolt M10 x 25 8.8 4
20 650469 8.3.7.00324 Spring Washer 10.5 x 16 x 1.5 4
21 650471 0.116.7203.00 Gasket 1
22 650473 0.132.6004.00 Gear Z21 M5.7 1
23 650474 8.0.1.00050 Bearing 6308 1
24 650476 0.116.7202.00 Gasket 1
25 709056 0.244.7500.00 Shim 51.5 1
26 650477 8.7.3.00044 Oil Seal 40 x 56 x 8 1
27 650489 8.4.7.01111 Cotter Pin B4 x 50 1
28 650482 8.4.7.00146 Cotter Pin B6 x 60 1
