2 650455 Gearbox – Comer 116.805 1
53 650472 PTO Assembly MDM70-60 Clutch 1
650493 PTO Half (Implement End) 1
650494 PTO Half (Tractor End) 1
54 709050 PTO Guard 1
55 2503105 Bolt 5 / 16 ” – 18 NC x 1 / 2 ” Hex Head 4
56 2502011 Washer 5 / 16 ” Springlock 4
57 2501012 Washer 5 / 16 ” Flat 4
9 34
S A F E T Y I N S T R U C T I O N S (continued) PA RTS LIST
M D M 7 0 - 6 0
( 5 F O O T M O W E R )
W I T H S H E A R B O LT
Mower operating power is supplied from tractor PTO. Refer to your tractor manual for PTO engagement and
disengagement instructions. Always operate the tractor PTO in the 540 rpm speed selection. DO NOT OVER
SPEED! Know how to stop tractor and mower quickly in case of an emergency.
All tractors that are not equipped with a “live” takeoff (PTO) need to be equipped with an over-running PTO
clutch type driveline. See page 23.
NOTE: The addition of a separate over-running PTO clutch attachment will change the length of the PTO
driveline. Pay extra attention to the instructions on PTO driveline installation.
Separate over-running clutch attachments will increase the length of the driveline and may cause the front
knuckle joint to operate beyond the cover of the tractor master shield. This is NOT recommended and will
present a dangerous operating condition.
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design. All operators of this equipment must read and understand this entire manual, paying
particular attention to safety and operating instructions, prior to using. If there is something in this manual you
do not understand, ask your supervisor, or your dealer, to explain it to you.
Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders at least several
hundred feet from an operating rotary mower. Only properly trained people should operate this machine.
When this machine is operated in populated areas or in other areas where thrown objects could injure persons
or property, standard equipment safety chain shielding (which is designed to reduce the possibility of thrown
objects) must be installed. If this machine is not equipped with full chain shielding, operation must be
stopped when anyone comes within several hundred feet.
The majority of accidents involve entanglement on the driveline, injury of bystanders by objects thrown by the
rotating blades, and operators being knocked off the tractor by low hanging limbs and then being run over by
the mower. Accidents are most likely to occur with machines that are loaned or rented to someone who has
not read the owner’s manual and is not familiar with a rotary mower.
Check the tractor master shield over the PTO stub shaft. Make sure it is in good condition and fastened
securely to the tractor. Purchase a new shield if old shield is damaged or missing. (You may have to use a
tractor salvage yard for replacement parts on older tractors.)
When engaging PTO, the engine RPM should always be low. Once engaged and ready to start cutting, raise
PTO speed to 540 RPM and maintain throughout cutting operation.
STARTING AND STOPPING SAFETY
OPERATIONAL SAFETY
1 650401 Deck Weldment MDM70-60 1
2 650450 Gearbox – Comer 116.802 S 2
3 2503086 Bolt 3 / 4 ” – 10 NC x 2” Hex Head Gr. 5 4
4 2500037 Nut 3 / 4 ” – 10 NC Hex Nylock 6
5 650418 Fill/Vent Plug 1
6 709052 Oil Level Plug 1
7 709052 Oil Drain Plug 1
8 650434 Castle Nut 1
9 650433 Bolt Washer 1
10 650482 Cotter Pin 1
11 650660 Blade Holder Weldment 1
12 650425 Blade, Mower SDM40-60/MDM70-60 2
13 650426 Blade Bolt 1 1 / 8 ” 2
14 650427 Lock Washer 1 1 / 8 ” HD 2
15 650428 Nut 1 1 / 8 ” – 12 UNF Hex Jam Gr. 8 2
16 650378 Sidebar, Toplink “A” 2
17 650379 Crossbar, Toplink “A” 1
18 650382 Linkage Lift Strap 2
19 650383 Tie Link, Toplink “A” 2
20 650384 Spacer 1
21 2503258 Bolt 3 / 4 ” – 10 NC x 2 1 / 4 ” Hex Head Gr. 5 2
22 590108 AK-578 Draw Pin 2
23 2503066 Bolt 5 / 8 ” – 11 NC x 4” Hex Head 1
24 2503154 Bolt 5 / 8 ” – 11 NC x 1 1 / 2 ” Hex Head Gr. 5 6
25 2503152 Bolt 5 / 8 ” – 11 NC x 2”Hex Head Gr. 5 1
26 2500041 Nut 5 / 8 ” – 11 NC Hex Nylock 4
27 650416 A-Frame Weldment, Tail Wheel 1
28 650413 Yoke Weldment – MDM Tail Wheel 1
29 2504049 Drive Zerk 5 / 16 ” 1
30 650332 Tail Wheel (4 x 8 x 15.25) 1
31 650545 Spacer 1 1 / 4 ” OD x 7 / 16 ” Lg. 1
32 650546 Spacer 1 1 / 4 ” OD x 1” Lg. 1
33 650098 Bearing Cone (L44643) 2
34 650115 Bearing Cup (L44610) 2
35 650117 Seal (CR124111) 2
36 2503259 Bolt 1” – 8 NC x 8” Hex Head Gr. 5 1
37 2500020 Nut 1” – 8 NC Hex Jam 1
38 2500001 Nut 1” – 8 NC Full Hex 1
39 2502009 Washer 1” Springlock 1
40 2504179 Roll Pin 1 / 2 ” x 2” 1
41 650544 Bar, Tail Wheel Adjustment 1
42 2502007 Washer 5 / 8 ” Springlock 4
43 2500013 Nut 5 / 8 ” – 11 NC Full Hex 4
44 650479 PTO Assembly MDM70-60 Shear 1
650491 PTO Half (Implement End) 1
650492 PTO Half (Tractor End) 1
45 2503151 Bolt 1 / 2 ” – 13 NC x 3” Hex Head Gr. 5 1
46 2502002 Washer 1 / 2 ” Springlock 1
47 2500003 Nut 1 / 2 ” – 13 NC Full HEx 1
48 2504201 Snap Ring 1 3 / 8 ” Dia. SH-137 1
49 101101 Safety Sign – Warning (540 RPM) 1
50 101100 Safety Sign – Danger (Rotating Blades) 1
51 101103 Safety Sign – Danger (Keep Away) 1
52 101157 Safety Sign – Warning (Prevent Injury) 1
PART
NO. DESCRIPTION
NO.
REQ.
REF.
NO.
M D M 7 0 - 6 0
( 5 F O O T M O W E R )
WITH SLIP CLUTCH
PART
NO. DESCRIPTION
NO.
REQ.
REF.
NO.
M D M 7 0 - 7 2
( 6 F O O T M O W E R )
WITH SLIP CLUTCH
1 650651 Deck Weldment MDM70-72 1
2 650455 Gearbox – Comer 116.805 S 1
12 650430 Blade, Mower SDM40-72/MDM70-72 2
18 650632 Strap, Lift Link 2
53 650475 PTO Assembly MDM70-72 Clutch 1
650497 PTO Half (Implement End) 1
650498 PTO Half (Tractor End) 1
54 709050 PTO Guard 1
55 2503105 Bolt 5 / 16 ” – 18 NC x 1 / 2 ” Hex Head 4
56 2502011 Washer 5 / 16 ” Springlock 4
57 2501012 Washer 5 / 16 ” Flat 4
PART
NO. DESCRIPTION
NO.
REQ.
REF.
NO.
M D M 7 0 - 7 2
( 6 F O O T M O W E R )
W I T H S H E A R B O LT
1 650651 Deck Weldment MDM70-72 1
12 650430 Blade, Mower SDM40-72/MDM70-72 2
18 650632 Strap, Lift Link 2
44 650470 PTO Assembly MDM70-72 Shear 1
650495 PTO Half (Implement End) 1
650496 PTO Half (Tractor End) 1
PART
NO. DESCRIPTION
NO.
REQ.
REF.
NO.
