02/10 52 51220 Rev. 1
Appendix III: Data Output
REMOTE DISPLAY OUTPUT
Data Format
<4><0>
Note(s):
1. Characters denoted by
X
are
characters 0-9.
2. Leading zeroes are suppressed.
3. Polarity indication for a positive value is a space (
SP
).
− Negative values are not transmitted.
4.
Identifier code <4><0> = Gross weight
.
− Transmission is Gross Only.
5. Transmission for the DEMAND Mode occurs when a carriage return (CR) Hex
0D
is received.
CONFIGURE OUTPUT
Fairbanks Data Format
Note(s):
1. Characters denoted by
G
and
T
are characters 0-9.
2. Leading zeroes are suppressed.
3. Gross Weight Data =
G
Tare Weight Data =
T
Status Code (Word) A
Bit # X00 X0 X X.X X.XX X.XXX X.XXXX X.XXXXX
0 0 1 0 1 0 1 0 1
1 0 0 1 1 0 0 1 1
2 0 0 0 0 1 1 1 1
