Section 4: Input/Output (I/O)
02/10 28 51220 Rev. 1
4.2.9. Other Data String Customization, Continued
Window Name Description
CONFIGURE OUTPUT,
CONTINUED
─ Tokens Tab
Programs the various data string tokens, such as the Motion flag.
Tokens are setup for the data protocol requirements.
Wrappers
─ Poll – Polling character for a demand output.
ƒ
Applicable only to the Demand Mode.
─ Start – The first character of a data string.
─ Stop – The last character of a data string.
─ Block – The character that separates the data fields.
Units – The character(s) used to define the unit of measure in the data
string
─ Primary – The main indicator unit of measure.
─ Secondary – The alternate indicator unit of measure.
Mode – The character(s) used to define the Weighing Mode in the
data string.
─ Gross – Character(s) used to designate the gross weight.
─ Tare – Character(s) used to designate the tare weight.
─ Net – Character(s) used to designate the net weight.
