Section 3: Service & Maintenance

04/10

17 51191 Rev. 2

3.2. GENERAL TROUBLESHOOTING

From the following chart, identify the symptom(s) and cause(s) of each malfunction,
solving each issue with an appropriate solution.

SYMPTOM

CAUSE

SOLUTION

Display Stays at Zero

1. Load Cell connections faulty.

2. Instrument faulty.

3. Damaged Interface Cables.

1. Cable replacement.

2. Service Instrument.

3. Test and replace according to

Subsection

3.2.3.

and

3.2.4.

Erratic Weights

Foreign object around load cells,
ramps, or under platform.

Excessive vibration near platform.

Instrument faulty.

Platform not level within ¼” (3.0°).

Surface not smooth within 1/8”.

Faulty/bad Load Cell.

1. Clear the area.

2. Remove the vibration source.

3. Service Instrument.

4. Level the platform surface.

5. Smooth the platform surface.

6. Test and replace according to

Subsection

3.2.3.

and

3.2.4.

Inaccurate Weights

1. Instrument out of span.

2. Instrument not properly adjusted to

zero.

3. Faulty/bad Load Cell.

1. Check and alter per the

Instrument Service Manual.

2. Zero the instrument according

to normal operation
procedures.

3. Test and replace according to

Subsection

3.2.3.

and

3.2.4.
