CASTER KIT INSTALLATION
1.
Raise the Lift two to four feet high
2.
Position each of the four Caster assemblies below the Crossbeam rails as shown on page 21 Figure # 6
and in below diagram.
3.
Install the four Pivot pins and Cotter pins to secure assembly to each column as shown below.
4.
Lower the Lift confirming that the Caster assemblies engage the Crossbeam rails and the four Columns
rise to clear the floor.
FOUNDATION REQUIREMENTS
Concrete shall have compression strength of at least 3,000 PSI and a minimum thickness of 4”.
CAUTION!
DO NOT use on asphalt or similar unstable surfaces.
SPECIAL NOTE
This Lift does not require bolting to the floor
(BUT)
If you choose the option to anchor the Lift to the floor please follow the detailed instructions and criteria below.
FOUNDATION and ANCHORING REQUIREMENTS
1.
Concrete shall have compression strength of at least 3,000 PSI and a minimum thickness of 4” in order
to achieve a minimum anchor embedment of 3 ¼”. NOTE: When using (¾” x 5 ½”) long anchors; if the top
of the anchor exceeds 2 ¼” above the floor grade, you DO NOT have enough embedment.
