4
This is a vehicle lift installation/operation manual and no attempt is made or implied herein to instruct the user in
lifting methods particular to an individual application. Rather, the contents of this manual are intended as a basis
for operation and maintenance of the unit as it stands alone or as it is intended and anticipated to be used in
conjunction with other equipment.
Proper application of the equipment described herein is limited to the parameters detailed in the specifications
and the uses set forth in the descriptive passages. Any other proposed application of this equipment should be
documented and submitted in writing to the factory for examination. The user assumes full responsibility for any
equipment damage, personal injury, or alteration of the equipment described in this manual or any subsequent
damages.
LIFT SPECIFICATIONS & FLOOR PLAN
Capacity 9,000 lbs
Lifting Height 84” (7’0”)
Ceiling Height to be height of highest vehicle to be raised plus 84” (7’ 0”)
Overall Length w/ Ramps 223-1/2” (18’ 7-1/2”)
Overall Length w/ no Ramps 192-1/2” (16’ 1/2”)
Overall Width 121” (10’1”)
Approach Ramp Length 31” (2’7”)
Runway Width 21-1/2” (1’ 9-1/2”)
Runway Length 188” (15’8”)
Runway Height 4-3/4”
Height of Columns 97” (8’1”)
Clearance between Columns 109.5” (9’1-1/2”)
Clearance between Runways 39”
Outside Runway to Outside Runway 79” (6’ 7”)
Clearance Under Runway 81” (6’ 9”)
Motor specs 110VAC, 1HP
Shipping Weight 2,350 LBS
