Direct Lift PP9 Plus - Manual (Page 34)

34
Item# Part Number Description Qty
44 SH4D-1500 TOP CAP A 2
45 SH4D-2001 CROSS RAIL, SAFETY LATCH COVER 4
46 NH4D-1012 BUSHING A 4
47 SH4D-2002 CABLE SHEAVE 10
48 NH4D-1013 BUSHING B 4
49 B10-8×30 BOLT M8×30 32
50 SH4D-2004 RUB BLOCK 8
51 NH4D-1009 LATCH SHAFT 4
52 NH4D-1014 BUSHING C 4
53 NH4D-1002 SAFETY LATCH A 2
54 NH4D-1003 LATCH 4
55 NH4D-1004 LATCH SPRING A 2
57 NH4D-1011 SAFETY LATCH SPRING 8
58 NH4D-1005 PLASTIC PULLEY 4
59 NH4D-1006 CABLE SHEAVE B SHAFT 4
60 SH4D-2003 CABLE SHEAVE SHAFT 4
61 B10-8×20 BOLT M8×20 4
62 SH4D-3100G DRIVER SIDE RUNWAY (MAIN SIDE) WELDMENT 1
63 NH4D-2002 BUSHING E , SPACER 4
64 NH4D-1012 BUSHING F , SPACER 2
65 SH4D-3001 RUNWAY CABLE SHEAVE SHAFT 4
66 NH4D-2005 LOCATING PLATE 4
67 B10-8×16 BOLT M8×16 8
68 SH4D-8020-4 CABLE A-3/8”×365.8” 1
69 SH4D-8020-3 CABLE B-3/8”×306.5” 1
70 SH4D-8020-2 CABLE C-3/8”×185.5” 1
71 SH4D-8020-1 CABLE D-3/8”×126.4” 1
72 B33-3/4”-16 NYLON LOCK NUT 3/4”-16 4
73 YG36-9100G HYDRAULIC CYLINDER 1
74 1WB-05 HYDRAULIC HOSE A - “WIRE BRADED” 1
75 SW-002(30400-9053YZ) FITTING WITH O-RING 1
76 H4D-Y003 90 DEGREE, BULKHEAD FITTING 1
77 SH4D-8010 HYDRAULIC HOSE B - 79.5” 1
78 PP7-9802-2 90 DEGREE FITTING 1
79 NH4D-2021 CABLE LOCK PLATE A 1
80 NH4D-2022 CABLE LOCK PLATE B 1
81 B33-27×2 NYLON LOCK NUT M27×2 1
82 B52-4×50 COTTER PIN Ш4Ч50 2
83 SH4D-8030 CYLINDER PIN 1
84 SH4D-5002 SAFETY RELEASE HANDLE B(HANDLE ROD) 1
85 SH4D-5001 SAFETY RELEASE HANDLE A(“T” ROD) 1
86 SH4D-5003 CONNECTING ROD A 2
87 SH4D-5004 CONNECTING ROD B 2
88 B72-6 SWIVER JOINT M6 8
