Direct Lift PP9 Plus - Manual (Page 33)

33
PROPARK 9 PARTS LIST
Item# Part Number Description Qty
1 SH4D-1000 COLUMN WELDMENT, POWER UNIT 1
2 SH4D-1100 COLUMN WELDMENT, PIN 3
3 SH4D-2100G CROSSBEAM WELDMENT 2
4 SH4D-3200G RUNWAY, PASSENGER SIDE(OFF SIDE) 1
5 SH4D-3000G RUNWAY, DRIVER SIDE(MAIN SIDE) 1
6 SH4D-8050 JACK TRAY / PARTS BOX 1
7 P3543 HYDRAULIC POWER UNIT - 110VAC 1
8 SH4D-7000 CASTER FRAME 4
9 SH4D-7100 CASTER FRAME PIN 4
10 H4D-5006-3 COTTER PIN 4
11 B30-10 NUT M10 16
12 B40-10 LOCK WASHER Ø10 16
13 B41-10 FLAT WASHER Ø10 32
14 B10-10×35 BOLT M10×35 16
15 B80-6×2A POLYURETHANE - CASTER WHEEL Ш6”Ч2” 4
16 B10-8×35 BOLT M8×35 4
17 B41-8 FLAT WASHERØ8 56
18 B40-8 LOCK WASHERØ8 20
19 B30-8 NUT M8 8
20 SH4D-6000G “DRIVE ON” RAMP 2
21 SH4D-8060G CONNECTING FRAME 4
22 SH4D-2012G COVER PLATE C 3
23 SH4D-1600 FOOT PLATE 1
24 SH4D-2011G COVER PLATE B 1
25 SH4D-2010G COVER PLATE A 2
26 NH4D-1142 INSIDE COVER PLATE 2
27 SH4D-8001G WHEEL STOP 2
28 NH4D-4006 BRACKET , CROSSBEAM 2
29 B23-6×10 SCREW M6×10 30
30 B41-6 FLAT WASHERØ6 34
31 B10-12×50 BOLT M12×50 8
32 B40-12 LOCK WASHER Ø12 24
33 B41-12 FLAT WASHERØ12 40
34 B31-16 NUT M16 GRADE 8.8 8
35 B41-16 FLAT WASHERØ16 16
36 B40-16 LOCK WASHERØ16 16
37 B11-16×40 BOLT M16×40 GRADE 8.8 16
38 SH4D-4000HJ LOCK LADDER 4
39 NH4D-3303 JAM NUT 4
40 B41-20 FLAT WASHERØ20 8
41 B30-20 NUT M20 4
42 B10-12×35 BOLT M12×35 16
43 B30-12 NUT M12 16
