Teledyne Analytical Instruments
34
7.3 Supplement to address map
* (a) Register No. 40076 to 40083 (response time 1 to 8)
The following shows signals corresponding to response time 1 to 8.
- 7500
Response time 1
1st component detector signal
Response time 2 2nd component detector signal
Response time 3 3rd component detector signal
Response time 4 Unused
The above does not include sensor signals of oxygen.
- 7600
Response time 1
1st component measurement detector signal
Response time 2 1st component interference compensation detector signal
Response time 3 2nd component measurement detector signal
Response time 4 2nd component interference compensation detector signal
Response time 5 3rd component measurement detector signal
Response time 6 3rd component interference compensation detector signal
Response time 7 4th component measurement detector signal
Response time 8 4th component interference compensation detector signal
The above does not include sensor signals of oxygen.
* (b) Register No. 30062 to 30131 (error log)
Up to 14 errors logged can be read in the order from the latest to older ones.
The contents are as follows.
Error No.: No. of produced error. Stored value is error number minus 1.
Error WEEK: Day when error occurred.
Error HOUR: Indicates at what o'clock error occurred.
Error MIN: Indicates at what minutes error occurred.
Error TARGET: No. of CH where error occurred.
CH No. minus 1 is stored.
0 at error No. 1, 2, 3 or 10.
No. of optical system where error occurred minus 1 if error No. is 1 in
case of 7600.
