Teledyne Analytical Instruments
29
Word data [read-out only]: Function code [04
H
]
Measurement value and status
Relative
address Register
No. Data
type Memory contents Read-on / Write-in
data Remarks or
corresponding
parameter Relevant
model
0000
H
30001 Word CH1 concentration R/K
0001
H
30002 Word CH1 decimal point position R/K
0002
H
30003 Word CH1 measurement unit R/K
0003
H
30004 Word CH2 concentration R/K
0004
H
30005 Word CH2 decimal point position R/K
0005
H
30006 Word CH2 measurement unit R/K
0006
H
30007 Word CH3 concentration R/K
0007
H
30008 Word CH3 decimal point position R/K
0008
H
30009 Word CH3 measurement unit R/K
0009
H
30010 Word CH4 concentration R/K
000A
H
30011 Word CH4 decimal point position R/K
000B
H
30012 Word CH4 measurement unit R/K
000C
H
30013 Word CH5 concentration R/K
000D
H
30014 Word CH5 decimal point position R/K
000E
H
30015 Word CH5 measurement unit R/K
000F
H
30016 Word CH6 concentration R/K
0010
H
30017 Word CH6 decimal point position R/K
0011
H
30018 Word CH6 measurement unit R/K
0012
H
30019 Word CH7 concentration R/K
0013
H
30020 Word CH7 decimal point position R/K
0014
H
30021 Word CH7 measurement unit R/K
0015
H
30022 Word CH8 concentration R/K
0016
H
30023 Word CH8 decimal point position R/K
0017
H
30024 Word CH8 measurement unit R/K
0018
H
30025 Word CH9 concentration K
0019
H
30026 Word CH9 decimal point position K
001A
H
30027 Word CH9 measurement unit K
001B
H
30028 Word CH10 concentration K
001C
H
30029 Word CH10 decimal point position K
001D
H
30030 Word CH10 measurement unit K
001E
H
30031 Word CH11 concentration K
001F
H
30032 Word CH11 decimal point position K
0020
H
30033 Word CH11 measurement unit K
0021
H
30034 Word CH12 concentration K
0022
H
30035 Word CH12 decimal point position K
0023
H
30036 Word CH12 measurement unit
Concentration: -
9999 to 9999
(value
corresponding to
indication without
decimal point)
Decimal point
position: 0,1,2,3
(0; concentration/1
1; concentration/10
2;
concentration/100
3;
concentration/1000)
Measurement unit:
0, 1, 2, 3
(0; vol%
1; ppm
2; mg/m
3
3; g/m
3
)
Transmit values
under current
measurement
conditions
K
