Teledyne Analytical Instruments
28
Word data [read-out/write-in]: Function code [03
H
, 06
H
, 10
H
]
User settings
Relative
address Register
No. Data
type Memory contents Read-on / Write-in data Remarks or
corresponding
parameter Relevant
model
005C
H
40093 Word Hold switch 0, 1
(0: OFF, 1: ON) Output hold R/K
005D
H
40094 Word Oxygen conversion reference
value 01H to 13H (1% to
19%) Oxygen
conversion
reference value R/K
005E
H
40095 Word Peak alarm switch 0, 1
(0: OFF, 1: ON)
005F
H
40096 Word Peak alarm concentration 0064H to 03e8H
(100 to 1000 ppm)
0060
H
40097 Word Peak alarm count 0001H to 0063H
(1 to 99 times) R/K
0061
H
40098 Word Peak alarm hysteresis 0000H to 0014H
(0 to 20% FS)
Setting of peak
alarm
R/K
0062
H
40099 Word Auto zero calibration start
time (day) 00H to 06H (Sun to Sat) R/K
0063
H
40100 Word Auto zero calibration start
time (hour) 00H to 23H ((BCD
code) R/K
0064
H
40101 Word Auto zero calibration start
time (min) 00H to 59H ((BCD
code) R/K
0065
H
40102 Word Auto zero calibration cycle R/K
0066
H
40103 Word Auto zero calibration cycle
unit 0,1 (0:h, 1: days) R/K
0067
H
40104 Word Auto zero calibration switch 0,1 (0:OFF, 1: ON) R/K
0068
H
40105 Word Auto zero calibration gas
flow time 003CH to 0257H (60 to
599 sec)
Setting of auto
zero calibration
R/K
0069
H
40106 Word CH1 range change setting R/K
006A
H
40107 Word CH2 range change setting R/K
006B
H
40108 Word CH3 range change setting R/K
006C
H
40109 Word CH4 range change setting R/K
006D
H
40110 Word CH5 range change setting
0,1 (0: range-1; 1:range-
2) Range
changeover
(disabled if
remote range
ON)
K
Word data [write-in]: Function code [06
H
]
Operation command
Relative
address Register
No. Data
type Memory contents Read-on / Write-in data Remarks or
corresponding
parameter Relevant
model
07D0
H
42001 Word Keying command 01H: MODE
02H: Side,
04H: Up, 08H: Down
10H: ESC, 20H: ENT
40H: ZERO, 80H: SPAN Sending a value
simulates keying R/K
07D1
H
42002 Word Display change 1: Return to measurement
mode display Force to return
to measurement
mode R/K
