Word data [read-out only]: Function code [04
H
]
Measurement value and status
Relative
address Register
No. Data
type Memory contents Read-on / Write-in
data Remarks or
corresponding
parameter Relevant
model
0024
H
30037 Word Peak count 0 to 100 times / hour
R/K
0025
H
30038 Word CH1 current range R/K
0026
H
30039 Word CH2 current range R/K
0027
H
30040 Word CH3 current range R/K
0028
H
30041 Word CH4 current range R/K
0029
H
30042 Word CH5 current range
0,1
(0: range-1; 1::range-
2)
K
002A
H
30043 Word CH1 high/low limit alarm R/K
002B
H
30044 Word CH2 high/low limit alarm R/K
002C
H
30045 Word CH3 high/low limit alarm R/K
002D
H
30046 Word CH4 high/low limit alarm R/K
002E
H
30047 Word CH5 high/low limit alarm
0,1,2
(0: No alarm,
1: High limit alarm,
2: Low limit alarm) Whether or how
alarm is currently
produced
K
002F
H
30048 Word Peak count alarm 0,1 (0: No, 1: Yes) R/K
0030
H
30049 Word Auto (Auto zero) calibration in
progress 0,1 (0: No, 1: Yes) R/K
0031
H
30050 Word CH1 zero calibration in
progress R/K
0032
H
30051 Word CH2 zero calibration in
progress R/K
0033
H
30052 Word CH3 zero calibration in
progress R/K
0034
H
30053 Word CH4 zero calibration in
progress R/K
0035
H
30054 Word CH5 zero calibration in
progress K
0036
H
30055 Word CH1 span calibration in
progress R/K
0037
H
30056 Word CH2 span calibration in
progress R/K
0038
H
30057 Word CH3 span calibration in
progress R/K
0039
H
30058 Word CH4 span calibration in
progress R/K
003A
H
30059 Word CH5 span calibration in
progress
0,1 (0: No, 1: Yes)
K
003B
H
30060 Word Instrument error 0,1 (0: No, 1: Yes) Whether error is
produced R/K
003C
H
30061 Word Calibration erro 0,1 (0: No, 1: Yes) Whether error is
produced R/K
003D
H
30062 Word Latest error no. R/K
003E
H
30063 Word Latest error WEEK R/K
003F
H
30064 Word Latest error HOUR R/K
0040
H
30065 Word Latest error MIN R/K
0041
H
30066 Word Latest error TARGET
-1 to 9 (Error No.-
1)*(b)
0 to 6 (Sun to Sat)
0 to 23 (hours)
0 to 59 (min)
0 to 4
Error log
contents
R/K
