Teledyne Analytical Instruments
26
Word data [read-out/write-in]: Function code [03
H
, 06
H
, 10
H
]
User settings
Relative
address Register
No. Data
type Memory contents Read-on / Write-in data Remarks or
corresponding
parameter Relevant
model
0014
H
40021 Word CH1 auto calibration switch R/K
0015
H
40022 Word CH2 auto calibration switch R/K
0016
H
40023 Word CH3 auto calibration switch R/K
0017
H
40024 Word CH4 auto calibration switch R/K
0018
H
40025 Word CH5 auto calibration switch
0, 1
(0: Dn not calibrate in
auto calibration
1: Calibrate in auto
calibration) Auto calibration
component
K
0019
H
40026 Word CH1 zero calibration switch R/K
001A
H
40027 Word CH2 zero calibration switch R/K
001B
H
40028 Word CH3 zero calibration switch R/K
001C
H
40029 Word CH4 zero calibration switch R/K
001D
H
40030 Word CH5 zero calibration switch
0, 1
(0: Selectable, zero
calibration
1: Zero calibration at
once) About zero
calibration
K
001E
H
40031 Word CH1 calibration range switch R/K
001F
H
40032 Word CH2 calibration range switch R/K
0020
H
40033 Word CH3 calibration range switch R/K
0021
H
40034 Word CH4 calibration range switch R/K
0022
H
40035 Word CH5 calibration range switch
0, 1
(0: Calibrate indicated
range only
1: Calibrate both ranges
at the same time) About calibration
range
K
0023
H
40036 Word CH1 range-1 high alarm setting R/K
0024
H
40037 Word CH1 range-1 low alarm setting R/K
0025
H
40038 Word CH1 range-2 high alarm setting R/K
0026
H
40039 Word CH1 range-2 low alarm setting R/K
0027
H
40040 Word CH2 range-1 high alarm setting R/K
0028
H
40041 Word CH2 range-1 low alarm setting R/K
0029
H
40042 Word CH2 range-2 high alarm setting R/K
002A
H
40043 Word CH2 range-2 low alarm setting R/K
002B
H
40044 Word CH3 range-1 high alarm setting R/K
002C
H
40045 Word CH3 range-1 low alarm setting R/K
002D
H
40046 Word CH3 range-2 high alarm setting R/K
002E
H
40047 Word CH3 range-2 low alarm setting R/K
002F
H
40048 Word CH4 range-1 high alarm setting R/K
0030
H
40049 Word CH4 range-1 low alarm setting R/K
0031
H
40050 Word CH4 range-2 high alarm setting R/K
0032
H
40051 Word CH4 range-2 low alarm setting R/K
0033
H
40052 Word CH5 range-1 high alarm setting K
0034
H
40053 Word CH5 range-1 low alarm setting K
0035
H
40054 Word CH5 range-2 high alarm setting K
0036
H
40055 Word CH5 range-2 low alarm setting
0 to 9999
Decimal point position
depends on range Alarm setting
K
