Teledyne Analytical Instruments
27
Word data [read-out/write-in]: Function code [03
H
, 06
H
, 10
H
]
User settings
Relative
address Register
No. Data
type Memory contents Read-on / Write-in
data Remarks or
corresponding
parameter Relevant
model
0037
H
40056 Word CH1 alarm mode R/K
0038
H
40057 Word CH2 alarm mode R/K
0039
H
40058 Word CH3 alarm mode R/K
003A
H
40059 Word CH4 alarm mode R/K
003B
H
40060 Word CH5 alarm mode
0, 1, 2
(0: High limit alarm,
1: Low limit alarm,
2: High or low limit)
K
003C
H
40061 Word CH1 alarm mode R/K
003D
H
40062 Word CH2 alarm mode R/K
003E
H
40063 Word CH3 alarm mode R/K
003F
H
40064 Word CH4 alarm mode R/K
0040
H
40065 Word CH5 alarm mode
0, 1, 2
(0: Alarm OFF,
1: Alarm ON)
K
0041
H
40066 Word Alarm hysteresis 0000H to 0014H (0
to 20% FS)
Alarm setting
R/K
0042
H
40067 Word Auto calibration start time (day) 00H to 06H (Sun to
Sat)
R/K
0043
H
40068 Word Auto calibration start time
(hour) 00H to 23H (BCD
code) R/K
0044
H
40069 Word Auto calibration start time (min) 00H to 59H (BCD
code)
R/K
0045
H
40070 Word Auto calibration cycle R/K
0046
H
40071 Word Auto calibration cycle unit 0,1 (0: h, 1: days) R/K
0047
H
40072 Word Auto calibration switch 0,1 (0: OFF, 1: ON) R/K
0048
H
40073 Word Auto calibration gas flow time 003CH to 0257H (60
to 599 sec)
Setting of auto
calibration
R/K
0049
H
40074 Word Key lock switch 0,1 (0: OFF, 1: ON) Key lock R/K
004A
H
40075 Word Remote range switch 0,1 (0: OFF, 1: ON) Remote range R/K
004B
H
40076 Word Response time 1 R/K
004C
H
40077 Word Response time 2 R/K
004D
H
40078 Word Response time 3 R/K
004E
H
40079 Word Response time 4 K
004F
H
40080 Word Response time 5 K
0050
H
40081 Word Response time 6 K
0051
H
40082 Word Response time 7 K
0052
H
40083 Word Response time 8 K
0053
H
40084 Word Oxygen meter response time
0000H to 0063H
(0 to 99 sec) *(a) Response time
R/K
0054
H
40085 Word 1st order moving average period R/K
0055
H
40086 Word 2nd order moving average period R/K
0056
H
40087 Word 3rd order moving average period R/K
0057
H
40088 Word 4th order moving average period
0000H to 003bH
(0 to 59 min or 1 to 4
h)
K
0058
H
40089 Word 1st order moving average period
unit R/K
0059
H
40090 Word 2nd order moving average period
unit R/K
005A
H
40091 Word 3rd order moving average period
unit R/K
005B
H
40092 Word 4th order moving average period
unit
0,1
(0: h, 1: min)
Average period
K
