Appendix
Teledyne Analytical Instruments 67
Appendix
A.1 Specifications and Initial Settings:
Range(s):
Power Requirements:
Signal Output: Two analog channels:
- Channel 1: 0-1 VDC and isolated 4-20
mADC
- Channel 2 0-1 VDC and isolated 4-20
mADC
User configures what each channel tracks:
CH4, non-CH4, Total HC, and Peak
traces.
Alarms: Two Concentration Alarm ‘C’ Type
relay contacts. User configurable.
One System Alarm for AC power failure
and flame out, fail safe, ‘C’ type relay
contacts.
Calibration Contact: Calibration Contact, ‘A’ Type Relay
contact for span mode indication.
RS232 Output: Provided
Ambient Temp: 0 – 40º C. Install in a well ventilated area
