Installation Series 4040
34 Teledyne Analytical Instruments
10 Remote Span +
11
12 Remote Span -
13
14
15
16 Span Solenoid Return
17 Span Solenoid Hot
18 Range 3 Contact
19 Range 3 Contact
20 Alarm 3 C Contact
21 Range 1 Contact
22 Range 2 Contact
23 - Output 0-1 v (Channel 2)
24 + Output 0-1 v (Channel 1)
25
26
27
28 Alarm 1 C Contact
29
30
31
32 Exhaust Solenoid Hot
33 Sample Solenoid Hot
34 Range 4 Contact/ not used
35 Range 4 Contact/not used
36 Alarm 3 NC Contact
37 Alarm 3 NO Contact
38 Range 1 Contact
39 Range 2 Contact
40 Calibration
Contact
41 Calibration Contact
42 Alarm 2 NC Contact
43 Alarm 2 NO Contact
44 Alarm 2 C Contact
45 Alarm 1 NC Contact
46 Alarm 1 NO Contact
47
48 Exhaust Solenoid Return
49
50 Sample Solenoid Return
