A-3
Oxygen Analyzer Appendix
Appendix
A-1 Models 3010 TA Specifications
Packaging: General Purpose Control Unit
• Flush panel mount (Standard).
• Rack mount — Relay rack mounted to
contain either one or two instruments in one
19" relay rack mountable plate (Optional).
Packaging: Explosion Proof Analysis Unit
NEMA 4 Instrument Enclosure. External gas
connector panel with flow indicator (flame
arrestors optional).
Sensor: L-2 trace Micro-Fuel Cell.
Cell Block: 316 stainless steel.
Ranges: Three user definable ranges.
0–10 ppm to 0–250,000 ppm.
Air calibration range 0-25 %.
Autoranging with range ID output.
Sample System: Positive pressure service.
Vacuum service (optional).
Auto Cal / Auto Zero with electrically oper-
ated valves. (Internal valves optional.)
Alarms: One system-failure alarm-contact to detect
power failure.
Two adjustable concentration threshold alarms
with fully programmable setpoints.
