5 Maintenance Model 3010 TA Oxygen Analyzer
5-4: Part I
x
Figure 5-4: Rear-Panel Screws
To detach the rear panel, remove only those four screws marked with an X .
5.4 Cleaning
If instrument is unmounted at time of cleaning, disconnect the instru-
ment from the power source. Close and latch the front-panel access door.
Clean outside surfaces with a soft cloth dampened slightly with plain clean
water. Do not use any harsh solvents such as paint thinner or benzene.
For panel-mounted instruments, clean the front panel as prescribed in
the above paragraph. DO NOT wipe front panel while the instrument is
monitoring your process.
x x
x
