Part I: 1-1
Oxygen Analyzer Part I: Control Unit
Introduction
1.1 Overview
The Analytical Instruments Model 3010TA Analyzer Control Unit,
together with a 3010T Analysis Unit, is a versatile microprocessor-based
instrument for detecting trace amounts of oxygen in a variety of gases.
Part I, this part, of this manual covers the Model 3010TA series General
Purpose flush-panel and/or rack-mount Control Units. (The Analysis Unit is
covered in Part II of this manual.) The Control Unit is for indoor use in a
nonhazardous environment only. The Analysis Units (or Remote Probes) it
controls can be designed for a variety of hazardous environments.
1.2 Control Unit Front Panel
The standard 3010TA Control Unit is housed in a rugged metal case
with all remote controls and displays accessible from the front panel. See
Figure 1-1. The front panel has a digital meter, an alphanumeric display, and
thirteen buttons for operating the analyzer.
