5 Maintenance
Model 3010
T
5-4: Part II
5.2.3 Removing the Micro-Fuel Cell
WARNING: DO NOT TOUCH THE SENSING SURFACE OF THE
CELL. IT IS COVERED WITH A DELICATE TEFLON
MEMBRANE THAT CAN LEAK CAUSTIC AND COR-
ROSIVE CHEMICALS WHEN PUNCTURED.
The Micro-Fuel cell is located inside the housing in a stainless steel cell
block. (See Figure 5-2.)
Figure 5-2: Removing or Installing a Trace Micro-Fuel Cell
3 4 5 6 9
7
1
8
2
HGN
10
Cell Block
Micro-Fuel Cell
O-Ring
Cell Holder
Lift Up
Gate
Cell Adaptor
(For B-2 or A-2
series cell)
