Trace Oxygen Analyzer

Maintenance

Teledyne

Analytical

Instruments

45

Maintenance

5.1 Routine Maintenance

Aside from normal cleaning and checking for leaks at the gas

connections, routine maintenance is limited to replacing the sensors and
fuses, and recalibration. For recalibration, see Section 4.4 Calibration.

WARNING: SEE WARNINGS ON THE TITLE PAGE OF THIS

MANUAL.


5.2 Sensor Replacement

The ZrO

2

sensors are sealed transducers with no electrolyte to

change or electrodes to clean. When the sensor reaches the end of its
useful life, it is replaced. The spent sensor should be discarded
according to local regulations.

5.2.1 Removing the Sensor

The ZrO

2

sensors is located inside the nylon cell block behind the

front panel.

To remove an existing cell (refer to Figure 5-1):

CAUTION:

POWER IS APPLIED TO THE INSTRUMENT
CIRCUITRY WHENEVER THE INSTRUMENT IS
CONNECTED TO THE POWER SOURCE. THE RED
SWITCH ON THE FRONT PANEL IS FOR SWITCHING
POWER ON OR OFF TO THE DISPLAYS AND
OUTPUTS ONLY.

1. Remove power to the instrument by unplugging the power

cord at the power source.
