SPP Pumps Auto Prime Medium Head Open Set ACE80-100 Workshop Manual - Manual (Page 8)

Manual No/Rev
W72-020E / 1
Workshop Manual for
ACE80/100 Diesel Driven Centrifugal Pumps
Our policy is one of continuous improvement and we reserve the right to alter specifications at any time
Page 8 of 21
7. PUMP ASSEMBLY PROCEDURE
6.1 Pump End Section Drawing
