Manual No/Rev
W72-020E / 1
Workshop Manual for
ACE80/100 Diesel Driven Centrifugal Pumps
Our policy is one of continuous improvement and we reserve the right to alter specifications at any time
Page 14 of 21
4.17 Fit vac pump and bleed filter with four M8
flanged bolts. (Figure 8)
4.18 Fit taper locks and pulleys to vac pump and
engine. (Figure 9)
4.19 Fit belt over the pulleys, fit the tensioner with
two M8 bolts, tension belt and mark bolt
heads on tensioner. (Figure 9)
4.20 Fit vac pump exhaust system and inlet pipe
work. (Figure 8)
4.20.1 Fit reducing bush and hose tail together and
fit bush to vac pump casing
4.20.2 Fit pipe with clips to hose tail on the vac
pump and hose tail on the priming tank
Figure 8
Figure 9
6.8 Option Builds
5.1 Fit spark arrester and Chalwyn valve.
(Figure 10)
5.1.1 Remove air filter assy.
5.1.2 Fit Chalwyn valve and inlet manifold
5.1.3 Remove tail pipe then fit spark arrester to
exhaust.
Fig
ure 10
5.2 Fit Bauers using the bolts supplied. See
diagram below (Figure 11)
Figure 11
5.3 Fit unit to skid using four M12 x 30 self
locking bolts and nuts. (Figure 12)
Figure 12
5.4 Fit unit to the trailer. (Figure 13)
5.4.1 Assemble trailer if necessary.
5.4.2 Fit unit to trailer assy. using six flanged, self-
locking M12 x 30 bolts and nuts.
