Workshop Manual for
ACE80/100 Diesel Driven Centrifugal Pumps
Manual No/Rev
W72-020E / 1
Our policy is one of continuous improvement and we reserve the right to alter specifications at any time
Page 13 of 21
This manual is a preliminary issue
for information only,
pending formal issue of
the complete manual.
4.7 Fit pump/engine assy. to chassis using two
M12 x 40 bolts for the pump three M12 x 35
bolts for the engine feet. (See Figure 4)
Figure 4
4.8 Wire up engine and fit engine switch and
hour meter using the switch bracket. (See
photo and wiring diagram (Figures 6 &7).
4.9 Fit fuel filter and fuel lines. (Figure 5)
4.9.1 Fit fuel filter using two M10 x 30 flanged,
self-locking bolts and M10 flanged, self-
locking nuts.
4.9.2 Fit banjo inserts with a banjo bolt and
copper washers to one input and one output
on the top of the filter.
4.9.3 Connect pipe with jubilee clips to engine and
the output banjo insert.
4.9.4 Connect pipe with jubilee clips to fuel tank
and input banjo insert.
Figure 5
Figure 6
4.10 Fit back prime. (See sectional drawing parts
150, 160, 170 and 230)
4.10.1 Fit adapter ½” BSP – ½” BSPT and adapter
½” BSPT - ⅜ BSPT to the non-return valve
4.10.2 Connect the above assy. to the tee piece.
4.10.3 Fit adapter ½” BSP - ⅜ BSPT to the back
wear plate.
4.10.4 Connect the two adapters using the hose
and fittings assy.
4.11 Fit Seal oil vent line to the top of the seal oil
chamber. (See parts 210-220 on Figure 1)
4.12 Make battery leads and connect battery to
engine and start motor (See figs 6 and 7).
4.13 Fit battery with two M12 x 30 bolts, taper-
lock washers and self-locking flanged nuts.
As well as the mat and the plate. (Figure 6)
4.14 Fit battery leads. (Figure 6)
4.15 Clip down cables. (Figure 6)
4.16 Fit hours run meter and wire up. (Figures 6
& 7)
Figure 7
