Workshop Manual for
ACE80/100 Diesel Driven Centrifugal Pumps
Manual No/Rev
W72-020E / 1
Our policy is one of continuous improvement and we reserve the right to alter specifications at any time
Page 15 of 21
This manual is a preliminary issue
for information only,
pending formal issue of
the complete manual.
5.4.3 Fit angle bracket onto the chassis with two
M12 x 30 flanged bolts and flanged nuts.
5.4.4 Fit clamp onto bracket with two M12 x 30
flanged bolts andflanged nuts
5.4.5 Place rear leg into clamp and tighten.
5.4.6 Bolt two lighting board brackets onto back of
chassis using two M6 x 10 flanged bolts and
two flanged nuts per bracket.
Figure 12
6.9 Final preparation
6.1 Test unit.
6.2 PDI unit.
6.3 Fit the labels and manual.
8. PUMP TEST PROCEDURE
