Megabit Modem 400F User Manual 83
C
C
ONFIGURATION
W
ORKSHEETS
This chapter provides worksheets where you can record your system settings and system
sessions configuration information prior to executing the procedures in
Chapter 4 through
Chapter 7 .
The information that you need to configure the modem is listed below. Contact your service
provider for this information. Use the worksheets in this appendix to record your configuration
information. When you begin configuration of the modem in
Chapter 4 , the procedures refer
you to the proper table so you can use the information you have recorded.
C
ONFIGURATION
I
NFORMATION
1 System mode Bridge/Router RFC 1483.
2 Bridge/Router:
• Configure as a Bridge only, as a Router only, or as a Bridge and Router.
• If Bridge or Router, choose LLC or VC-MUX encapsulation.
• If Router, choose version of and direction for RIP (RIP1, RIP2, or RIP1 compatible).
• If Bridge, select whether or not to enable Spanning Tree.
3 Session address for Ports 1 through 32 (WAN configuration):
• ATM VPI and ATM VCI (specified for each session)
• when using fixed IP addresses, IP address specified for each session by the
service provider
