Hardware
74
Megabit Modem 400F User Manual
H
ARDWARE
The following provides additional information about Megabit Modem 400F such as the
installation kit and modem connectors pinouts.
Installation Kit
The following items are included in the installation kit and are used to install the Megabit
Modem 400F as shown in
Part
Description
Function
Rubber feet
Four black rubber feet
Attaches to the base of the modem.
Grey cable
Silver-satin phone cord with 4-pin modular
plugs (straight-through)
Connects the modem ADSL connector to the
wall phone jack for access to the Internet.
Black cable
CAT 5, cable with 8-pin modular plugs
(straight-through)
Connects the modem 10/100BASE-T connector
to the LAN through a hub or to a PC NIC.
Power cable
Power supply with optional power cord (this
item is ordered dependent on the type of
power supply and cord required for your
location)
Connects the modem POWER connector to the
local power source.
Screws
Two 6x
1
/
2
-inch sheet metal screws
Installs into a wall for wall-mounting modems.
Grey cable
and adapter
Flat cable with RJ-45 connectors and a DB-9
to RJ-45 adapter.
Connects the RS-232 MGMT port to an ASCII
terminal or a PC running terminal emulation
software. Adapter assembly connects to a DB-9
connector on the PC. Then, one RJ-45 connector
installs in the adapter and the other connector
into the console port on the modem.
