Diagnostic
51 F8138801
Factory Valve Purge Menu
The Factory Valve Purge Menu is used to allow the
factory to purge all the valves inside the machine after
the machine has been manufactured and tested.
Press the keypad to activate the step. The step
will run for five (5) minutes unless the keypad is
pressed.
Test Balance Weight Menu
The Test Balance Weight Menu is used to check and
display the current machine balance type and its status.
The machine must be equipped with a variable
frequency motor drive. The display shows the balance
switch status: CLOSED, 1 Hz, 2 Hz, 3 Hz, or OPEN.
The keypad initiates the test. Press the
or keypad to end the test. A UNLOCK key press
command will be recognized while the test is not in
operation. Press the or keypad again and
the display to return to the Test Menu.
PHM1057R
Figure 63
Factory Valve Purge
Press START
to Begin
FACTORY VALVE PURGE
PHM1285R
Figure 64
Test Balance Weight
PHM128 R
Press START
to Begin
TEST BALANCE WEIGHT
Balance Input Status
PASS
