Diagnostic

Diagnostic Menu

The Diagnostic Menu contains Test, Alarm and
Machine ID Menus. The menus contain specific
diagnostic information and manufacturing data for the

machine. The

and

keypads

position the highlighted box. Press the

keypad to

select the menu choice.

Press the

keypad while in the Diagnostic Menu

to return to System Menu.

Test Menu

The Test Menu provides features for manufacturing
and customer service testing. The highlighted box is

moved horizontally and vertically using the

and

keypads. Press the

keypad to select the menu choice.

Press the

keypad to return to Diagnostic Menu.

PHM1265R

Figure 61

Alarms

Machine ID

Test

Water Leak

Detection

Diagnostic Menu

PHM1056R

Figure 62

Test Menu

Inputs Outputs

Factory Valve

Purge

Test Balance

Weight

Test Cycle
