Global Setup
45 F8138801
Shakeout Menu
The Shakeout Menu is used to set the Shakeout time
after the Extract Step. The and keypads
adjust the time. The time can be set from 0-120
seconds in increments of 20 seconds.
Press the or keypad to enter the Save
Changes Menu. Press or to move
highlighted box to “Yes” or “No”. Press the
keypad to return to Global Setup Menu. If no changes
were made, press the or keypad to return
to Global Setup Menu.
Banners Menu
The Banners Menu is used to create or modify the
banners that are displayed while the machine is on the
Cycle Menu. The banners are displayed at the top of
the screen.
The banners are created or modified using the String
Edit Mode. Refer to Program Menu, Modify Cycle
section. Use the or keypad to highlight
the different lines and press the keypad to edit
the string. Pressing the keypad will jump to the
Save Changes Menu. Use or to move
highlighted box to “Yes” or “No”. Press the
keypad to return to Global Setup Menu. If no changes
were made, press the or keypad to return
to Global Setup Menu.
Factory Defaults Menu
The Factory Defaults Menu is used to set parameters
in the software back to the factory default. Several
parameters can be set individually back to the factory
settings and all Cycles and Global settings can be
restored. The individual parameters that can be set
back to the factory settings are the water level, water
temperature, alarms, and audio settings.
Press the directional keys to navigate through the
screen. Press the keypad to make a selection.
Once the keypad is pressed, Save Changes
Screen displays. Use or to move
highlighted box to “Yes” or “No”. Press the
keypad to return to Global Setup menu. If no changes
were made, press the or keypad to return
to Global Setup Menu.
PHM1046R
Figure 52
PHM1047R
Figure 53
Shakeout Menu
Shake Out Time
Sec 40
Banners
Banner #1
Banner #2
PHM1048R
Figure 54
Factory Defaults
Water
Temperature Only
Restore All Cycles and Global
Settings to Factory Defaults
Water Level Only
Alarms Only Audio Only
