Global Setup

F8138801

Alarms Program Menu

The Alarms Program Menu is used to set the fill,
drain, and heat alarm times.

The

and

keypads are used to move the

highlighted box through the different items in the
Alarm Program Menu. Once the item is highlighted,

the value can be changed by using the

and

keypads. Pressing the

keypad will jump to the Save Changes Menu.

Use

to move highlighted box to “Yes”

or “No”. Press the

keypad to return to Global

Setup menu. If no changes were made, press the

keypad to return to Global Setup Menu.

Rapid Advance Menu

The Rapid Advance Menu has the option of whether
the user will be able to rapid advance through steps

while the machine is operating. Press the

keypad to change the selection. All

the keypads have the same effect and will toggle the

selection between on or off. Press the

keypad to jump to the Save Changes Menu. Use

to move highlighted box to “Yes” or “No”.

Press

keypad to return to Global Setup Menu. If

no changes were made, press the

keypad to return to Global Setup Menu.

If the Rapid Advance Option is enabled (refer to
Global Setup, Rapid Advance section), the user can
advance a running machine cycle with presses of

the

keypad. When the

keypad is pressed,

the control will immediately show the next cycle step
in the Run Menu but will not change the outputs for a
period of at least five (5) seconds. The user may
advance into any cycle step except the Spray Rinse
Extract and Extract Steps. If the control is executing a

Drain step and the user presses

to execute a

Rapid Advance, the control will skip over the Extract
Step. When the cycle is completed, the audit counter,
Total Rapid Advance Cycles is incremented rather
than the Total Machine Cycles audit counter. In
addition this cycle is recorded in the audit list “Last 25
Machine Cycles Completed” and the audit list “Last
10 Machine Cycles Rapid Advanced/Aborted.” Refer
to UniLinc PC and PDA Application User
Instructions for additional information on using a
PDA.

In the Run Menu, the total remaining cycle time is
reduced by the corresponding advance step time if
programmed. If the Rapid Advance Option is disabled
preventing a manual Rapid Advance, the user may still
execute a Rapid Advance using the PDA.

PHM1044R

Figure 50

PHM1045R

Figure 51

Alarms

Fill

Drain

Heat

Rapid Advance

Enable the Rapid Advance

Feature During Cycle Operation?

Yes
