Machine Cycle Definition and Operation
F8138801 20
Run Menu
Run Menu provides cycle, segment, and step
information while the machine is operating. Refer to
Figure 7.
Supplies are only shown during the fill and supply
steps.
During the agitate steps the type of agitation is shown.
During the extract steps, the extraction speed displays.
Figure 7
Cycle01: Towels White Bleach
Segment06: Rinse
Extract
Extract Speed
Very High
Run Menu
PHM1007R
05:30
Cycle01: Towels White Bleach
Segment01: Wash
Drain
Run Menu
PHM1005R
35:02
HOT LOW
Cycle01: Towels White Bleach
Segment01: Wash
Agitate
A g i t a t e Ty p e
18F/3P/18R
Run Menu
PHM1006R
38:14
HOT LOW
Cycle01: Towels White Bleach
Segment01: Wash
Fill
Run Menu
PHM1071R
41:43
E S I
S I S 2 S 3 S 4 S 5
E S 2
E S 3
E S 4
E S 5
E S 6
E S 7
E S 8
PHM1071R PHM1006R
PHM1005R PHM1007R
