Machine Cycle Definition and Operation

F8138801

To Start a Cycle

1. Press the

keypad to change cycles.

2. Press the

keypad to move the cycle in the

rightmost menu box to the center, highlighted
position.

3. Press the

keypad to move the cycle in the

leftmost menu box to the center, highlighted
position.

4. Moving the

and

keypads allows the

Cycle Menu to scroll through the center,
highlighted position.

5. Press

to start selected cycle.

NOTE: Press and hold

keypad to

make highlighted area move rapidly.

NOTE: If door is not closed when the

keypad

is pressed, display will jump to the Close Door
Menu.

NOTE: If the machine has operated over 200 hours
and the Lubricate Bearings has not been reset from
the System Menu the Global Settings, a reminder
screen will pop up. The Lubricate Bearings Menu
will be display for five seconds and the Cycle Menu
will display for five seconds. This will occur until
the Bearing Timer is reset in the System Menu. The
Lubricate Bearings Menu will only be shown
during the Cycle Menu.

Every night at midnight the control will enter Service
Schedule Menu if the machine is in idle mode on the
Cycle Menu.

When a keypad is pressed or the door is opened or an
IR communication takes place the control will turn the
LCD contrast on and the backlight back on (if
programmed).

Control will also enter specific service sub-menu for
that day.

Quarterly Menu displays on the first day of the month
for January, April, July and October.

Monthly Menu displays on all other first days of the
month.

Weekly Menu displays on a Monday not on the first
day of the month. All other days the control will
display the Daily Menu.

Press any keypad to clear the menu and enter Cycle
Menu.

Optional settings are performed by either pressing a
keypad or by a combination of keypad presses:

• Press the

keypad to jump control to the

Contrast Adjust/Backlight Menu.

• Press the

keypad to enter the Service

Schedule Menu.

• Press and hold

then

to enter Delayed

Start Menu.

• Press and hold

then

enter the System Menu.

• Press the

keypad on the Cycle Menu to

unlock door.

A Banner is displayed above the Cycle Selections in
the Cycle Menu. If Banner 1 and Banner 2 are
programmed, Banner 1 displays for ten (10) seconds
and Banner 2 displays for ten (10) seconds. If only one
Banner is programmed it will be the only one shown.
Refer to Banner Menu Section.

During communication with the PDA, all menus enter
IR Communications Menu.
