Exploded Assembly Drawing for Installation of
Fig. Nos. 1071, 1072, 1081 and 1082 Series
Flush Locks & Latches
Fig. 1071/1072 Series Lock Sets
Fig. 1081/1082 Series Latch Sets
Straight Cam Bar
Flush Cam Bar
Offset Adjustable
Cam Bar
Flexible Plastic Strike -
Used only with Flush or
Straight Cam Bars, if
desired.
Back Up Nut
Spacer
Mounting Gasket
(Supplied on Figs. 1081 & 1082
series only) For installation on
smooth surfaces
DO NOT USE ON CARPETED
SURFACES
Set Screws
