Model No.PI-8127

Specifications

9

Specifications

Technical Support

For assistance with any PASCO product, contact PASCO at:

Limited Warranty
For a description of the product warranty, see the PASCO catalog.

Copyright
The PASCO scientific 012-10425A Function Generator Instruction Manual is copyrighted with all rights reserved. Permission is
granted to non-profit educational institutions for reproduction of any part of this manual, providing the reproductions are used only in
their laboratories and classrooms, and are not sold for profit. Reproduction under any other circumstances, without the written con-
sent of PASCO scientific, is prohibited.

Trademarks
PASCO, PASCO scientific, DataStudio, PASPORT, Xplorer, and Xplorer GLX are trademarks or registered trademarks of PASCO sci-
entific, in the United States and/or in other countries. For more information visit www.pasco.com/legal. Windows is a registered trade-
mark of Microsoft Corporation in the United States and/or other countries. Mac is a trademark of Apple Computer, Inc., registered in
the U.S. and other countries.

Product End of Life Disposal Instructions:
This electronic product is subject to disposal and recycling regulations that vary by country and region. It is
your responsibility to recycle your electronic equipment per your local environmental laws and regulations to
ensure that it will be recycled in a manner that protects human health and the environment. To find out where
you can drop off your waste equipment for recycling, please contact your local waste recycle/disposal service,
or the place where you purchased the product.

The European Union WEEE (Waste Electrical and Electronic Equipment) symbol (to the right) and on the prod-
uct or its packaging indicates that this product must not be disposed of in a standard waste container.

Input Power

15 V at 1.6 A

Voltage Output

±10 V at up to 1 A

Frequency Range

DC to 100 kHz with two ranges: 0.001 Hz to 999.999 Hz and
0.001 kHz to 100.000 kHz (150 kHz for Sine Wave)

Frequency Resolution

0.001 Hz for the lower range and 1 Hz for the upper range

Offset Voltage

±10 V

External Voltage Input

±10 V Maximum

Trigger Output

TTL compatible (0 to 5 V)

Waveforms

Sine, Square, Triangle, Positive Ramp, Negative Ramp, DC,
Mod Sine, Mod Square, Mod Pos Ramp, Mod Neg Ramp

Default Displays

Frequency, Voltage, Current, Waveform

Display

LCD Graphics Monochrome, 128 by 64 pixels, 2-level
Backlight

Address: PASCO scientific

10101 Foothills Blvd.
Roseville, CA 95747-7100

Phone:

916-786-3800 (worldwide)
800-772-8700 (U.S.)

Fax:

(916) 786-3292

Web:

www.pasco.com

Email:

[email protected]
