Verification
102 Series N5700 User’s Guide
Test Record Form – Agilent N5744A and N5764A
Agilent N5744A and N5764A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both − 10 mV
Vout − 20 mV
19.98 V
Vout − 40 mV
__________
__________
__________
__________ + 10 mV
Vout + 20 mV
20.02 V
Vout + 40 mV
CV Load Effect Both − 4 mV __________ + 4 mV
CV Source Effect Both − 4 mV __________ + 4 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both N/A
N/A __________
__________ 60 mV
8 mV
Transient Response
Voltage @ 1ms
Both − 100 mV __________ + 100 mV
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
N5744A
N5764A
N5744A
N5764A
N5744A
N5764A
N5744A
N5764A − 38 mA
− 76 mA
Iout − 114 mA
Iout − 228 mA
37.924 A
75.848 A
Iout − 152 mA
Iout − 304 mA
__________
__________
__________
__________
__________
__________
__________
__________ + 38 mA
+ 76 mA
Iout + 114 mA
Iout + 228 mA
38.076 A
76.152 A
Iout + 152 mA
Iout + 304 mA
CC Load Effect
N5744A
N5764A − 12.6 mA
− 20.2 mA __________
__________ + 12.6 mA
+ 20.2 mA
CC Source Effect
N5744A
N5764A − 5.8 mA
− 9.6 mA __________
__________ + 5.8 mA
+ 9.6 mA
Test Description N5744A Setting N5764A Setting
Voltage Programming & Readback, Min Voltage 0 V, 0 A 0 V, 0 A
Voltage Programming & Readback, High Voltage 20 V, 0 A 20 V, 0 A
CV Load Effect, Source Effect, Ripple and Noise 20 V, 38 A 20 V, 76 A
Transient Response 20 V, from 3.8 A to 34.2 A 20 V, from 7.6 A to 68.4 A
Current Programming & Readback, Min Current 0 A, 20 V 0 A, 20 V
Current Programming & Readback, High Current 38 A, 20 V 76 A, 20 V
CC Load Effect, Source Effect 38 A, 20 V 76 A, 20 V
Load Requirements N5744A N5764A
Current shunt 0.01Ω 100 A 0.01Ω 100 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 0.53Ω 1kW 0.26Ω 2kW
