Model No. PS-2138

Experiment

17

®

Analysis

In this analysis, use units of m/s /s or m/s

2

for acceleration, rad/s for

angular velocity, and rad /s/s or rad/s

2

for angular acceleration.

Tangential Acceleration

1) Look at graphs of Angular Acceleration vs. Time and Tangential

Acceleration vs. Time together.

*

How are the graphs related?

2) Create a graph of Tangential Acceleration vs. Angular Acceleration

and apply a linear fit.

*

What is the slope of the best-fit line (including

units)?

3) Write the equation of the best fit line in terms of a

T

,

α and slope. Does

the relationship represented by the best-fit line support the prediction
that you made earlier?

4) What physical quantity is represented by the slope? Measure this

quantity directly and compare it to the value of slope.

*Tangential
Acceleration is
measured by the
sensor as
“Acceleration, Y.”

*Plot Tangential
Acceleration on the
vertical axis and
Angular Acceleration
on the horizontal
axis.
