MEMORY OPERATION
Talking Timer is equipped with a memory feature that permits storing a countdown
time which may be recalled with a single press of the MEMORY button. Use it to
store a frequently used countdown time.
Storing a countdown time in memory
1. Slide the mode switch to the COUNT DOWN position.
2. Press HRS, MIN, and SEC buttons to set the countdown time. A voice
announces the entered value if the voice feature is active. Press and hold
buttons for rapid advancement.
3. Once the desired countdown time appears on the display, press the MEMORY
button to store the setting. (A steady “Memory” indicator appears.)
Recalling memory
1. While in the Countdown mode, verify a countdown time is stored in memory by
viewing the steady “Memory” indicator.
2. Press MEMORY button to recall the preset countdown time. The “Memory”
indicator flashes.
3. Press START/STOP button to begin the countdown.
Clearing memory
1. While in the Countdown mode, verify a countdown time is stored in memory by
viewing the steady “Memory” indicator.
2. Press MEMORY button to recall the preset countdown time. The “Memory”
indicator flashes.
3. While the “Memory” indicator flashes, press the CLEAR button to clear the memory
and display to zero.
COUNT-UP TIMER (STOPWATCH) OPERATION
Starting a count up
1. Slide the mode switch to the COUNT UP position.
2. Press START/STOP button to begin counting up.
Note: An unlimited number of time-outs may be taken. See “Time-Outs” section.
3. The count up will continue until stopped. Halt the count up by pressing the
START/STOP button.
4. With the count up stopped, press the CLEAR button to return the display to zero.
CONTINUOUS TIMING
The maximum count-up time is 23 hr, 59 min, 59 sec. After reaching 23 hr, 59 min, 59
sec, Talking Timer rolls over automatically and continues timing from zero. For timing
that lasts over 24 hours, simply count how many times the unit has rolled over and
continued timing.
TIME-OUTS
If a pause in the countdown or count-up timing operation is required, press the
START/STOP button to “freeze” the display at the current reading (time-out). To
resume timing from the point it was stopped, press the START/STOP button again. An
unlimited number of time-outs may be taken.
SIMULTANEOUS MODE USE
The Count-up, Countdown and Clock modes may be used simultaneously. For
example: Start a countdown in the Countdown mode. Switch to Count-up mode to start
a count up time. Switch to the CLOCK position to view the time of day. Countdown and
count-up continue to run as shown by the flashing indicators on the display.
SELECTING ALARM SOUNDS
There are six different countdown alarm sounds at zero.
Alarm sound Symbol displayed
Beep
Whistle
Cuckoo
Alarm sound Symbol displayed
Bell
Hopping coil
Car horn
Follow these steps to select one of the unique alarm sounds.
1. Slide open the front bottom one-third of the unit’s case to reveal the ALARM
SOUND button.
2. While the unit is in Countdown mode, press the ALARM SOUND button to select
an alarm sound. Continue pressing the ALARM SOUND button to scroll through
all available alarm sounds. Each alarm is indicated by a unique symbol on the
display.
The alarm may be selected while the countdown is stopped or running. The alarm
sounds are only available when the unit is in Countdown mode. They will not
function when the unit is in Count-up or Clock mode.
ALL OPERATIONAL DIFFICULTIES
If this timer does not function properly for any reason, please replace the batteries with
new, high quality batteries (see “Battery Replacement” section). Low battery power
can occasionally cause any number of “apparent” operational difficulties. Replacing
the batteries with new, fresh batteries will solve most difficulties.
BATTERY REPLACEMENT
An incorrect display, no display, or operational difficulties indicate that the batteries
should be replaced. Follow these steps to replace the batteries.
1. Flip up the clip on back of the unit to expose the battery compartment.
2. Slide open the battery compartment using your thumb.
3. Remove the exhausted batteries and replace them with two new batteries.
4. Replace the battery compartment cover.
Equivalent replacement batteries are: Control Company No. 1039, Eveready 357,
Rayovac RW42, and Duracell D357.
Warranty, Service, or Recalibration
For warranty, service, or recalibration, contact:
CONTROL COMPANY
4455 Rex Road Friendswood, Texas 77546 USA, Ph. 281-482-1714, Fax 281-482-9448
E-mail [email protected], www.control3.com
Control Company is ISO 9001 Quality-Certified by DNV and ISO 17025 accredited as a Calibration
Laboratory by A2LA.
Rev. 1 110705
Control Company Cat. No. 5015
Traceable
® is a registered trademark of Control Company © 2008 Control Company
