Attaching the Electrode Holder to the Meter
Attaching the electr
ode holder to the meter
facilitates one-hand operation.
Attach two
electr
ode holders if you have a separate electr
ode
and temperatur
e pr
obe.
1.
Locate the slot on the left hand side of the meter
.
2.
Gently slide the flange of the holder into the slot on the meter
. Make sur
e the holder is
secur
ed pr
operly into the slot.
See figur
e
Y
ou can attach the electr
ode holder in dif
fer
ent
positions. See figur
e
T
o
attach a second electr
ode holder:
3.
Align the flange of the second electr
ode holder
with the slot of the first holder
.
See figur
e
4.
Slide the flange of the second holder into the slot of the first holder until the tops of the holders ar
e aligned and secur
e.
Inserting the Electrode into the Electrode Holder
Do not use excessive for
ce when inserting electr
odes into the holders.
1.
Insert the pH electr
ode into the opening of the first holder until the top housing
of the electr
ode touches the top of the holder
.
2.
If you ar
e using a separate temperatur
e pr
obe, insert the pr
obe into the opening
of the second holder until the ridge on the housing touches the top of the holder
.
NOTE:
The holder is designed for pr
obes 12 mm in diameter
. Electr
odes lar
ger than
12 mm may not fit in the holder
. For
cing the electr
ode into the opening may
damage the holder or your electr
ode.
B A
B A
3.4
C
C
