Connecting the Electrode and T
emperature Probe
The OAKT
ON pH/mV meter can use any standar
d pH, ORP
, or ISE electr
ode with a
BNC connector
. For automatic temperatur
e compensation (A
TC), this meter r
equir
es
a temperatur
e pr
obe with a specialty 6-pin connector
.
Use either: •
any electr
ode with a BNC connector and a separate temperatur
e pr
obe with
6-pin connector (part number 35618-05)
•
an “All-in-One” combination pH electr
ode/temperatur
e pr
obe designed
specifically for the pH 300 and pH 310 waterpr
oof meters
NOTE:
Keep connectors clean. Do not touch connector with soiled hands.
See the “Accessories” section on page 45
for a temperatur
e pr
obe and “All in One”
electr
odes for use with the pH 300 and pH 310 meters.
3.2
T
o
connect the pH, ORP or ISE electrode:
1.
Slide the BNC connector of the pr
obe over the BNC connector socket on the
meter
. Make sur
e the slots of the connector ar
e in line with the posts of the
socket. Rotate and push the connector clockwise until it locks.
See figur
e below
.
2.
T
o
r
emove pr
obe, push and r
otate the connector counter
clockwise. While
holding onto the metal part of the connector
, pull pr
obe away fr
om the meter
.
CAUTION: Do not pull on the pr
obe cor
d or the pr
obe wir
es might disconnect.
T
o
connect the temperature probe:
1.
Line up the notch and 6 pins on the meter with the holes in the 6-pin connector
.
Push down and turn the locking ring clockwise to lock into place.
See figur
e below
.
2.
T
o
r
emove pr
obe, turn the locking ring counter
clockwise on the pr
obe connector
.
Pull pr
obe away fr
om the meter
.
CAUTION: Do not pull on the pr
obe cor
d or the pr
obe wir
es might disconnect.
Temperature probe (with 6-pin connector)
locking ring
Electrode (with BNC connector)
top view of 6-pin
connector of
temperature probe
