DYNAPACE Incline Wave Feed Conveyor User Manual
Adjustable incline transfer conveyor
ITE 318 / ITE 324
Adjustable Incline Transfer Conveyor
P e o p l e a n d P r o d u c t s Y o u C a n R e l y O n
Module:
ITE 318 (18W) / ITE 324 (24W) Adjustable Incline Transfer Conveyor
Frame Style:
Precision welded steel framing with painted panels
Description:
The adjustable incline transfer conveyor is designed for easy set-up and alignment.
This conveyor is generally used to feed various wave solder machines under
SMEMA control.
Standard Features:
Programmable logic controller ( Continuous running without PLC available)
Adjustable incline angle (0 - 9 degrees)
Adjustable height 30"- 42" (762mm – 1067mm) (on exit side, at 6 degrees)
Operator controls (release, E-stop, reset, Manual load/transfer audit)
Variable speed (2 - 25 fpm) (.61 – 7.6 mpm) continuous run
Precision slide for quick width adjustment
Operator controls (E-stop, Reset)
Left to right travel, front fixed rail
Designed for minimal maintenance
ESD grounding receptacles
Painted sheet metal panels, “Dynapace White”
Conforms to SMEMA Spec. 1.2 and NFPA 79
Includes 1 standard communication cable
Product Handling Capability:
Edge Contact:
0.187” (5mm) Others Available 0.187”
Length:
5.0” – 18” (127mm - 457mm)
5” – 18”
Width: (C17251)
(C17251A)
2.5” – 18” (63.5mm - 457mm)
2.5" - 24" (63.5mm - 609.6mm)
2.5” – 18”
2.5" - 24"
Thickness:
0.031” (.787mm) minimum
0.031” minimum
Weight:
Up to 5lbs (2.7kg) per foot
Above board clearance:
N/A N/A
Below board clearance:
1.0” (25.4mm) 1.0”
Facilities Requirements:
Electrical:
115 VAC/60Hz 15 amp
Air:
N/A
Footprint: (C17251)
(C17251A)
24"L X 36" L. (609 L x 904mm W)
24"L x 42"W (609 L x 1067mm W)
PO Box 7 Palatine, IL 60078
•
847-398-5757
•
Sales Fax 847-852-3377
•
www.dynapace.com
C17251 (18" wide) C17251A (24" wide) 082005
