DYNAPACE Inverter User Manual
Bie 300, Edge carry board inverter
BIE 300
Edge Carry Board Inverter
P e o p l e a n d P r o d u c t s Y o u C a n R e l y O n
Module:
BIE-300 Edge Carry Board Inverter
Frame Style:
Precision welded steel framing with painted panels
Description:
Intelligent edge carry conveyor used to invert a PCB for second side assembly.
Standard Features:
Clamshell design for full top access
Fast “center axis” invert and transfer (<10 seconds)
Programmable Logic Controller
Variable speed (10-45 fpm) (3 – 13.7mpm) Other available
Dual belt design
Precision slide for quick width adjustment
Operator controls (E-Stop, cycle stop, start/reset, invert Yes / No)
Audible alarm
“Look up” product sensors
Left to right travel, front fixed rail
ESD grounding receptacle
Painted sheet metal panels, “Dynapace White”
Conforms to SMEMA Spec. 1.2 and NFPA 79
Includes 1 standard communication cable
Product Handling Capability:
Edge Contact:
0.187” (5mm)
Length:
3” – 20” (76mm - 508mm)
Width:
3” – 18” (76mm - 457mm)
Thickness:
0.045” (1.1mm) minimum
0.120” (3mm) maximum
Weight:
Up to 5 lbs (2.7kg) per foot
Above board clearance:
0.5” (13mm)
Below board clearance:
0.5” (13mm)
Facilities Requirements:
Electrical:
115 VAC/15 amp
Air:
60 PSI 5CFM
Line height:
37” +/- 2” (940mm +/- 51mm)
Footprint:
26”L x 41”W (660mmL x 1041mmW)
