DYNAPACE FIFO Storage Buffers User Manual
Sbe 420 fifo, Buffer system – 20 slot
SBE 420 FIFO
Buffer System – 20 Slot
P e o p l e a n d P r o d u c t s Y o u C a n R e l y O n
Module:
SBE-420 FIFO Buffer System – 20 Slot
Frame Style:
Precision welded steel framing with painted panels
Description:
A vertical buffering conveyor (First In, First Out) providing up to 20-board capacity,
that allows control of varying PCB flow.
Standard Features:
Programmable Logic Controller
Variable speed (10-30 fpm) (3 – 9.14mpm)
Hand crank width adjustment
Touch screen interface for machine status viewing
Advanced touch screen controls with password protection
Audible alarm / 3 color light tower
First in, first out (FIFO) operation
Selectable pitch settings (1”, 2” or 3”)
Left to right travel, front fixed rail
ESD grounding receptacles
Painted sheet metal panels, “Dynapace White”
Conforms to SMEMA Spec. 1.2 and NFPA 79
Includes 1 standard communications cable
Product Handling Capability:
Edge Contact:
0.187” (5mm) Others Available
Length:
5” – 20” (127mm - 508mm)
Width:
3.5” – 18” (89mm - 457mm)
Thickness:
0.031" (.7874mm) minimum
Above board clearance:
Varies dependant on pitch setting
Below board clearance:
Varies dependant on pitch setting
Facilities Requirements:
Electrical:
115 VAC/60 Hz 15 amp
Air:
N/A
Line height:
37” +/- 1” (940mm +/- 25mm)
with 6” above floor clearance for utility track
Footprint:
50"W X 24" L. X 80" H
(1270mm W x 609mm L x 2032mm H)
