REPLACEMENT PARTS LIST
*Part number is determined by one or more of the following: model number, voltage, or
motor shaft diameter and keyway sizes.
**Number of rotating friction discs, stationary discs, and rotating friction disc stabilizer clips is
shown in the brake model number. Example: -62006- has two rotating discs, two stationary
discs, and two stabilizer clips (when used).
***For use with Models 4-60000-530 and 6-60000-5116 only. Items 27 and 28 require motor
shaft diameter and keyway size.
11
Item
No.
Description
NEMA 4
6-60000-543
4-60000-530
NEMA 4X
6-60000-5115
6-60000-5116 Qty.
15R Carriage bolts 1/4-20 UNC G060803-001 2
15S
Torque spring (blue) 1.5 lb.ft. models
Torque spring (silver) 3 & 6 lb.ft. models
Torque spring (bronze) 10 & 15 lb.ft. models
Torque spring (green) 20 & 25 lb.ft. models G060791-001
G060792-001
G060793-001
G060794-001 1
1
1
15T Lock nut 1/2-20 UNC W003013-001 1
16 Hex hd. capscrew 1/4-20 x 1/2 lg. W001008-001E 1
17 Nylon bushing G060820-001 1
18 Plain brass washer W004003-024 1
19 Hex nut 5/16-18 UNC W003002-002E 1
20 Cover K060465-001 K060465-021 1
21 Instruction label (not shown) K060495-001 2
22 Nylon washer W004015-001 1
23 Acorn nut 1/4-20 UNC W003005-001A W003005-001B 1
24 O-ring for bracket W006001-023 1
25 Pipe plug 1/8 NPT W010002-001 W010002-001B **
26 Nameplate drive screw #4 type U W001012-048 W001012-048A **
27 V-ring hub seal assembly (includes items 38-30) H060555-*** **
28 V-ring hub assembly (includes item 29) G060814-*** 1
29 Setscrew #10-32 UNF x 1/4 lg. W002001-061-*** 1
30 V-ring (V-50A) W011008-002*** 1
31 Gasket mounting face H060344-003 H060344-004 1
32 O-ring for release W006001-025 1
33 Socket screw cap plug 3/8 hex W008006-004 1
34 Socket screw cap plug 3/16 hex W008006-001 2
35 Release label G060859-001 1
Item
No.
Description
NEMA 4
6-60000-543
4-60000-530
NEMA 4X
6-60000-5115
6-60000-5116 Qty.
1 Hub K060107-* 1
2
Bracket 1 & 2 disc
3 disc
4 disc
L060266-001 L060266-031 1
L060266-002 L060266-032 1
L060266-003 L060266-033 1
3 Release Knob G060848-001 1
4 Release return spring G060881-001 1
5 Release adjustment screw W001002-056C 1
6 Release adjustment spring G060795-001 1
7 Nameplate K060507-001 K060467-001 1
8 Pipe plug 1/2” NPT W010002-004 W010002-004A 1
9 Cover stud G060337-001 2
10 Pivot stud W002005-303A 1
11
Compression spring, 1.5 - 15 lb.ft.
Compression spring, 20 and 25 lb.ft. G060821-001 1
G060852-001 1
12 Stationary disc H060147-001 **
13 Rotating friction disc H0060157-003 **
14 Stabilizer clip for rotating friction disc H060466-001 **
15 Operator assembly K060476-*P 1
15A Magnet assembly, Plated 1
15B Magnet shock mount 1
15C Magnet mounting bracket H060544-001 1
15D Hex head capscrew 1/4-20 UNC x 1/2 lg W001008-001E 2
15E
Armature assembly (not shown)
(Includes items 15F through 15Q)
H060541-* 1
15F Armature plate H060545-003 1
15G Nyliner bushing W013005-001 2
15H Wear adjustment screw sq hd. 1/4-20 UNC x 1-1/2 lg W002003-001 2
15I Roll pin 5/32’ ida. x 3/8” lg W005003-098 1
15J Armature lamination assembly G060788-002 1
15K Armature shock mount G060808-003 1
15L Armature spacer G060798-002 2
15M Hex hd. capscrew 1/4-20 UNC x 5/8 lb. Grade 5 W001007-002E 2
15N Locking plate G060812-001 1
15P Split spring lockwasher #8 W004006-003 1
15Q Soc. hd. capscrew #8-32 UNC x 1/4 lg W001013-201 1
*Specify brake model/serial no.
