Diamond Products CC4130E-XL User Manual
Page 49
2800653 STARTER BOX
ITEM
PART NO.
QTY.
DESCRIPTION
1
2800909
1
Enclosure, 20" x 14" x 6"
2
2800910
1
Subpanel
3
2801801
1
Sounder Alarm
4
6011329
1
Stop Button Assembly
5
6011097
1
Start Button Assembly
6
2800224
1
Battery Charge Ammeter
7
2801802
1
Ammeter, 50 Amp
8
2707338
1
Disconnect Handle
9
6080020
1
Disconnect Rod
10
2803038
1
Motor Controller, Soft Start
11
2701274
1
Rectifier Bridge
12
2801433
1
Circuit Breaker, 5A, Single Pole
13
2801434
1
Circuit Breaker, 25A, Single Pole
14
2800248
1
Current Transformer
15
2801804
1
Power Relay
16
2801803
1
Relay Socket
17
2801435
1
Circuit Breaker, 3A, Double Pole
18
2701422
1
Disconnect Block
19
2800315
1
Grounding Lug
20
2701299
1
Transformer, 500VA
21
2801432
1
Contactor, 24V Coil
22
2800335
2
Auxiliary Contact
23
2701295
1
Power Relay, 12V-DC
24
2800552
1
Connector, 1/2" Cord
25
2800272
1
Connector, 1" Sealtite, Straight
26
2802604
1
Insulating Bushing, Plastic, 1"
